HUBBELL CANADA INC. HBL24W49 Twist-Lock® Watertight Locking Plug 15 A, 250 V, Industrial Grade
hubhbl24w49
HUBBELL CANADA INC. HBL24W49 Twist-Lock® Watertight Locking Plug 15 A, 250 V, Industrial Grade
Inventory
Unavailable for order
Manufacturer:HUBBELL CANADA INC.
Manufacturer #:HBL24W49
Description
Twist-Lock® Plug. Smooth body design minimizes collection points simplifying the wash down process. Strain relief nut always seals on the body, minimizing debris collection. Stainless steel hardware and corrosion-resistant connection points.
Specifications
| Brand Name | Hubbell Wiring Device Kellems | Sub Brand | Twist-Lock® |
| Item Name | Watertight Locking Plug | Type | Industrial Grade |
| Number of Wires | 3 | Number of Poles | 2 |
| Voltage Rating | 250 V | Amperage Rating | 15 A |
| Conductor Size | 16/3 SJ - 10/3 SJ, 18/3 S - 12/3 S AWG | NEMA Configuration | L6-15P |
| Color/Finish | Yellow | Cord Type | SJ, S |
| Cord Size | 3/8 - 5/8 in | Phase | 1 |
| Terminal Connection | Screw | Temperature Rating | -40 to 60 °C Continuous |
| Contact Material | Nickel Plated Brass | NEMA Rating | L6-15P |
| Dielectric Strength | 2500 VAC | Material | Thermoplastic Elastomer |
| Degree of Protection | IP69K | Dimensions | 1.85 in dia x 3.21 in L |
| Environmental Conditions | Watertight | Standards | UL 498, CSA C22.2 No. 42, NEMA WD-1, WD-6, NEMA Type 4, 4X, 12, 6, 6P, NSF Certified |
| Application | Industrial/Commercial | UPC | 783585131252 |
