omrd4cc4031
OMRON CANADA INC. D4CC4031 LSW,1A,125VAC,SLD PIN PLUNGER
omrd4cc4031
OMRON CANADA INC. D4CC4031 LSW,1A,125VAC,SLD PIN PLUNGER
Price
$260.00
/ EA
Inventory
3for delivery
0for pick up at
Burlington
Manufacturer:OMRON CANADA INC.
Manufacturer #:D4CC4031
Description
Compact limit switch, connector type, 1 A 30 VDC,
Specifications
| Brand Name | Omron | Item Name | Safety Limit Switch |
| Type | General-Purpose | Actuator | Sealed Pin Plunger |
| Voltage Rating | 30 VDC | Contact Configuration | SPDT |
| Travel | 1.8 mm Pretravel, 3 mm Overtravel | Dimensions | 40 mm W x 16 mm D x 67.5 mm H |
| Series/Model | D4CC | Amperage Rating | 1 A at 30 VDC |
| Indicator Type | LED | Operating Cycles | 10000000 Mechanical, 200000 Electrical |
| Mounting Type | Front | Degree of Protection | IP67 |
| Temperature Rating | -10 to 70 °C | Environmental Conditions | 35 - 95% Humidity, 10 - 55 Hz Vibration, 1000 m/s² Destruction Shock, 500 m/s² Malfunction Shock |
| Standards | CSA C22.2 No. 14, UL 508 | UPC | 612647145500 |
Packages
| 1 - rarr_unit_1 |
